Perkins generator set

The Perkins diesel generator set uses original Perkins engines, which have a complete product range, wide power coverage, excellent stability, reliability, durability, and service life. It can provide you with low operating costs and fast "payback" cycles, and is widely used in communication, industry, outdoor engineering, mining, risk resistance, military and other fields. Our company has decades of professional experience in producing Perkins diesel generator sets. The Perkins series diesel generator sets we produce have the characteristics of small size, light weight, strong power, energy conservation, environmental protection, high reliability, and easy maintenance, which can meet the needs of different customers.

Instructions for use:
1. The standard technical parameters of the unit are 50Hz, rated voltage 400/230V, power factor 0.8. The wiring method is three-phase four wire. The generator is selected from well-known brands such as Stanford, Leysinma, and Marathon.
2. Customizable 60Hz, medium and high voltage (690V, 6000V, 10500V).

CONTACT

Related Products

Unit model	Power				Diesel engine model	Diesel engine power		Unit size （mm）	Weight（kg）
	Commonly used		Spare			Commonly used	Spare
	Kva	Kw	Kva	Kw		Kw	Kw
TNKP7Z	9	7.2	9.9	7.92	403A-11G1	9.5	10.45	1350x500x1090	335
TNKP9Z	11.2	9	12.38	9.9	403D-11G	11.8	12.98	1350x500x1090	335
TNKP10Z	13.1	10.4	14.3	11.44	403A-15GL	13.5	14.85	1430x500x1150	400
TNKP12Z	15.8	12.7	17.5	13.97	403D-15G	16.2	17.82	1435x500x1150	415
TNKP12Z	15	12	16.5	13.2	403A-15G2	15.1	16.61	1435x500x1150	415
TNKP16Z	20.2	16.2	22.3	17.8	404D-22GL	20.6	22.66	1610x560x1195	525
TNKP19Z	24	19.2	26.4	21.12	404D-22G	24.3	26.73	1610x560x1195	525
TNKP26Z	32.9	26.3	36.16	28.93	404D-22TG	33.3	36.63	1680x560x1195	550
TNKP24Z	30	24	33	26.4	1103A-33G	31	34.1	1840x700x1270	860
TNKP36Z	45	36	49.5	39.6	1103A-33TG1	46.5	51.15	1960x700x1350	870
TNKP48Z	60	48	66	52.8	1103A-33TG2	60.5	66.55	2050x700x1350	980
TNKP50Z	65	52	71.5	57.2	1104A-44TG1	65.5	72.05	2200x700x1350	1050
TNKP64Z	80	64	88	70.4	1104A-44TG2	80.5	88.55	2200x700x1350	1080
TNKP80Z	100	80	110	88	1104C-44TAG2	103	113.3	2280x700x1350	1250
TNKP100Z	135	108	148.5	118.8	1106A-70TG1	139.9	153.89	2565x850x1425	1522
TNKP120Z	150	120			1106A-70TAG2	153.5		2750x850x1350	1580
TNKP140Z	180	144			1106A-70TAG3	185.5		2850x850x1350	1590
TNKP160Z	200	160			1106A-70TAG4	202		2850x1045x1825	1600
TNKP200Z	250	200			1506A-E88TAG3	245		2980x1055x1695	2350
TNKP240Z	300	240			1506A-E88TAG5	293		3080x1090x1700	2500
TNKP280Z	350	280			2206C-E13TAG2	305		3460x1150x2030	2980
TNKP320Z	400	320			2206C-E13TAG3	349		3460x1150x2030	3135
TNKP360Z	455	364			2506C-E15TAG1	434		3780x1270x2020	3760
TNKP400Z	500	400			2506C-E15TAG2	435		3780x1270x2020	3880
TNKP450Z	591	473			2806C-E18TAG1A	514		3780x1536x2180	4555
TNKP500Z	650	520			2806A-E18TAG2	565		3780x1536x2180	4600
TNKP600Z	746	600			4006-23TAG2A	682		4250x1690x2150	6460
TNKP640Z	800	640			4006-23TAG3A	705		4250x1690x2150	6500
TNKP700Z	900	720			4008TAG1A	805		4735x2261x2256	7400
TNKP800Z	1022	818			4008TAG2A	899		4735x2261x2256	7450
TNKP900Z	1125	900			4008-30TAG3	1105		4735x2261x2256	7450
TNKP1000Z	1250	1000			4012-46TWG2A	1113		4800x2100x2297	9030
TNKP1200Z	1500	1200			4012-46TAG2A	1331		4900x2100x2297	9730
TNKP1300Z	1710	1368			4012-46TAG3A	1500		4900x2100x2297	9730
TNKP1450Z	1850	1480			4016TAG1A	1588		5035xx2597x2150	10300
TNKP1600Z	2000	1600			4016TAG2A	1766		5035xx2597x2150	10300
TNKP1800Z	2250	1800			4016-61TRG3	1975		5250xx2600x2150	11000
