Cummins generator set（CCEC）

The Cummins diesel generator set uses Dongfeng (DCEC)/Chongqing (CCEC) Cummins engines, which have high reliability, easy maintenance, long continuous operation time, and ultra long working hours, and have won the love of users in industries such as ports, railways, and industrial and mining enterprises. As a foreign investor in the Chinese engine industry, Cummins owns manufacturing companies such as Dongfeng Cummins Engine Co., Ltd. (producing B, C, and L series) and Chongqing Cummins Engine Co., Ltd. (producing M, N, and K series) in China, and produces according to Cummins quality standards. Cummins Global Service Network provides customers with reliable service guarantees.

Instructions for use:
1. The standard technical parameters of the unit are 50Hz, rated voltage 400/230V, power factor 0.8. The wiring method is three-phase four wire. The generator is selected from well-known brands such as Stanford, Leysinma, and Marathon.
2. Customizable 60Hz, medium and high voltage (690V, 6000V, 10500V).

CONTACT

Related Products

Unit model	Power				Diesel engine model	Diesel engine power		Unit size （mm）	weight（kg）
	Commonly used		Spare			Commonly used	Spare
	Kva	Kw	Kva	Kw		Kw	Kw
TKC200Z	250	200	275	220	MTA11-G2	224	246	270010501915	2750
TKC200Z	250	200	275	220	MTA11-G2	224	246	270010501915	2750
TKC250Z	312.5	250	350	280	MTAA11-G3	282	310	280010501915	2850
TKC200Z	250	200	275	220	NT855-GA	231	254	300010501780	2900
TKC200Z	250	200	275	220	NTA855-G1	240	264	300010501780	2900
TKC200Z	250	200	275	220	NTA855-G1	240	264	300010501780	2900
TKC220Z	275	220	312.5	250	NTA855-G1A	264	291	300010501780	3000
TKC250Z	312.5	250	350	280	NTA855-G1B	284	321	300010501780	3000
TKC250Z	312.5	250	350	280	NTA855-G1B	284	321	300010501780	3000
TKC250Z	312.5	250	350	280	NTA855-G2	284	321	300010501780	3000
TKC275Z	343.75	275	375	300	NTA855-G2A	312	343	300010501780	3100
TKC280Z	350	280	387.5	310	NTA855-G4	317	351	300010501780	3100
TKC300Z	375	300	412.5	330	NTAA855-G7	343	377	300010501780	3300
TKC360B	-----	-----	450	360	NTAA855-G7A	-----	407	300010501780	3300
TKC300Z	375	300	412.5	330	KTA19-G2	336	370	358012772065	3950
TKC360Z	450	360	500	400	KTA19-G3	403	448	370012752100	2900
TKC400Z	500	400	562.5	450	KTA19-G3A	448	504	370012752100	4250
TKC400Z	500	400	562.5	450	KTA19-G4	448	504	370012752100	4300
TKC420Z	525	420	631.25	505	KTAA19-G5	470	555	386017352310	4550
TKC460Z	575	460	650	520	KTAA19-G6	520	570	405515502235	4550
TKC520B	-----	-----	650	520	KTA19-G8	-----	575	365016802095	4550
TKC550B	-----	-----	687.5	550	KTAA19-G6A	-----	610	405515502210	4700
TKC550B	-----	-----	687.5	550	KTAA19-G7	-----	610	405515502210	4700
TKC500Z	500	500	700	560	KT38-G	560	615	405515502210	6000
TKC570Z	712.5	570	787.5	630	KTA38-G1	634	701	420016502210	6150
TKC570Z	712.5	570	787.5	630	KTA38-G1B	634	701	420016502210	6150
TKC580Z	725	580	800	640	KT38-GA	647	711	420016502210	6400
TKC600Z	750	600	825	660	KTA38-G2	664	731	435017502210	6600
TKC640Z	800	640	887.5	710	KTA38-G2B	711	789	435017502210	6700
TKC728Z	910	728	1000	800	KTA38-G2A	813	896	435017502210	6850
TKC800Z	1000	800	1100	880	KTA38-G5	880	970	435020902210	7150
TKC1000B	-----	-----	1250	1000	KTA38-G9	-----	1089	435020902210	7250
TKC1000Z	1250	1000	1375	1100	KTA50-G3	1097	1227	496020702330	9140
TKC1000Z	1250	1000	1375	1100	KTA50-G3	1116	1227	496020702330	9240
TKC1020Z	1275	1020	1375	1100	KTA50-G12	1148	1210	496020702330	9340
TKC1100Z	1375	1100	1650	1320	KTA50-G8	1200	1429	505022602455	9400
TKC1180Z	1475	1180	1650	1320	KTA50-GS8	1287	1429	525021702540	9600
TKC1340Z	1675	1340	1875	1500	KTA50-G15X	1491	1656	530021702540	10000
TKC1600Z	2000	1600	2062.5	1650	KTA50-G16B	1760	1810	540022002600	10800
